Highlights
- Original instrumentation provided by Ortho-Clinical
- Diamond Down-To-Frame® refurbishment provided.
- Refurbishment includes disassembly and total restoration.
- Process continues with assembly, repair, and diagnostics.
- Certification concludes with calibration, QC and QA validation.
- Contact Diamond for pricing, specifications and availability.
Assays
********(***), *************(***), ********(*****), ******(***), ******(******), *************(****), *************(***), *************(***), ***********(******), **************(****), **************(******), *******(***), *********(****), *******(*****), **************(******), ************(*****), ********(****), ******(***), **********(******), *************(***), ***************(*****), ***********(******), *******(*****), ***************(******), ******(***), ***************(******), *********(***), ***************(***), ************(****), ********(***), *************(****), **************(***), *************(****), ***********(****), *************(******), ********(***), ******(*****), *************(***), *********(***), **************(******), *************(***), ************(****), ******(***), *******(*****), **************(****), ********(***), *******(*****), *************(******), ******(******), ********(****), **********(*****), ***************(*****), ***********(***), ***********(***), *******(******), ************(******), **************(******), **************(******), ******(****), *************(***), **********(******), ********(*****), *************(***), ******(***), ***************(****), ********(*****), ***************(****), ************(***), **********(****), **********(******), ******(******), *********(*****), *******(***), ***************(*****), **********(****)
Specifications
| Manufacturer: | Ortho-Clinical |
| Series: | Vitros |
| CLIA Complexity: | Moderate |
| Sample Types: | CSF, Plasma, Urine, Whole Blood, Serum |
| Number of Assays: | 75 |
| Maximum Throughput: | 845 tests/hour |
| Sample Cycle Time: | 150 (sec) |
| Sample Size Min: | 2 μL |
| Direct Sample (STAT): | Yes |
| Auto Sample Handling: | No |
| Sample Input Type: | Sample Cups Sample Tubes |
| Reagent Type: | Dry |
| Reagent System: | Closed |
| Reagent Capacity: | 125 |
| On-Board Refrigeration: | No |
| Configuration: | Floor Model |
| Height: | 133 cm (52 in) |
| Width: | 234 cm (92 in) |
| Depth: | 84 cm (33 in) |
| Weight: | 640 kg (1408 lb) |
| Water Requirement: | No |
| Power Supply: | 220V |
| Point Of Care: | No |
| Other Features: | VITROS MicroSlide Technology delivers high-quality results with a 95% reportable result efficiency- minimizing operator interventions and maximizing ease of use. True workflow consolidation with 80 tests on board (45 MicroSlide, 35 MicroTip) and 125 Reagent positions. No water or drain required; selfcontained onboard waste management eliminates special requirements for off-board plumbing. |
